How many installation methods are there for Solar Road Studs?

Date:2023-03-02

Ruichen Youtube Channel
- This is a professional 【Road Studs】 manufacturer


The Solar Road Studs can be glued or cemented, and nailed for a little more stability. Charged by solar energy, it automatically emits light at night and when there is insufficient light in rainy and foggy weather, which can guide the vehicle in the correct direction and effectively ensure traffic safety. It is widely promoted because of its convenient installation and use and effective energy saving.

Solar Road Studs Use Occasions:
1. There are more than four lanes back and forth, but there is no isolation belt in the middle and the roadside stones with insufficient light at night
2. Use Solar Road Studs at crossroads/zebra crossings (deceleration reminder)
3. Sharp turning road
4. Foggy areas (seaside, airport road)

5. Solar Road Studs on the edge stones of highways and roads without street lights
6. Location of guide lines at the entrance and exit of elevated roads and tunnels
7. Road islands, vehicle diversions (around the triangular horizontal line)
8. Railway ramp entrance
9. On the lane line of the toll station
10. Accident-prone areas
11. Urban sidewalks, park paths, etc. need to beautify the night scene and other areas and road surfaces. It can be pasted with glue or cement. If you want to be more stable, add Solar Road Studs glue
Product parameter description
1. Power supply mode: solar panel (monocrystalline silicon) 2.5V/120MA
2. Energy storage device: high temperature battery 1200MAH or farad capacitor 240F
3. Working hours of Solar Road Studs: Under standard light intensity, it can work continuously for 72 hours a day after charging, and can work for more than 100 hours when fully charged
4. Display mode: flashing or always on
5. Display color: white, yellow, red, green, blue optional
6. Display device: 3 or 6 5MM super bright LED lights; single/double side optional
7. Solar Road Studs viewing distance: >500 meters
8. Service life: The service life of battery type is 3~5 years
9. Working environment: -20℃~+70℃
10. Material: die-casting aluminum + imported PC material, anti-UV, anti-yellowing, high pressure resistance
11. Dimensions: length, width and height, 110*97*24.5MM
12. Packing size: 34*24*28CM; 48PCS/box, 2PC/small
13.Solar Road Studs waterproof and compression resistance: IP68, compression resistance: greater than 100KN
